Pedal powered bandsaw, build thread



Posts: 7
2
  • Likes 3
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
After building a business using a now 112 year old, treadle powered printing press I was sold on the ability of human powered machines. My press was 1000 lbs of cast iron that moved like butter under the gentle press of my foot. I’m dreaming of a fully off-grid workshop, utilizing human and direct solar power. Aside from boatloads of research and experimentation, this is my first attempt at making this dream a reality. So far I’ve got a working frame and drivechain. I hope to install a sprocket onto the bandsaw and have it running shortly. I fully expect to tear it apart and rebuild it a few times. That being said, the first major problem I’ve found is with the direction of rotation. I’m orser to pedal while cutting the rider has to pedal backwards. The best solution for inverting roller chain involves 4 sprockets. Any other ideas that won’t cost much more than free?
[Thumbnail for B3F7DAA5-2181-4586-AB37-E881091F99A1.jpeg]


Posts: 7
2
  • Likes 1
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
Also, please excuse my ugly welds. I’ve tested them harder than I should have, but they aren’t pretty at all. This is my first big welding project in 15 years.

steward
Posts: 3702
Location: woodland, washington
200
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
to reverse the direction of the chain, make it into a figure-eight. the trick then is to keep the chain from rubbing against itself. I can think of a couple ways to do that, but I'm guessing you can, too.

for all but the lightest work, I think you'll probably want a stout flywheel involved if there isn't one already. maybe the existing bandsaw wheels are enough, though.


Posts: 7
2
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
I plan on adding a flywheel to the mix just to make the load lighter, but from my experience small kerf blades need a fraction of the torque of larger ones (bandsaw vs tablesaw).

pollinator
Posts: 872
Location: Thunder Bay, Ontario, Canada
175
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
I like the idea of a power takeoff on tractors because you can have one portable power unit and multiple things that can attach to it.

pollinator
Posts: 920
Location: Central Ontario
171
kids dog books chicken earthworks cooking solar wood heat woodworking homestead
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
The figure 8 suggested should work. I have seen pvc guide tubes well greased used to reduce chain chatter and occasional contact...
Looks cool...

gardener
Posts: 945
Location: SW Missouri • zone 6 • ~1400' elevation
400
fish trees chicken sheep seed woodworking
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
I don't know if this would introduce new problems like increased friction or earlier failure, but if the chain sprocket under the saw had a gear next to the sprocket, on the same shaft, and that drove a gear on the same shaft as the pulley or whatever drives the saw blade, I'm pretty sure that would reverse the direction.

I know that's a run on sentence. Let me know if it's unclear. Maybe I could draw something or mark my idea on your photo.
