Rico Loma wrote:Thom, good start sir, keep us posted. Others here can give advice more expertly than I.
I think a majority of folks use one clay to 3 sand, then mix in straw ....was your grass dry in your mixing?
One trick I learned in Cub Scouts camping, to avoid a thrashing at home, was to smear dishwashing soap on the pot before the open fire....an easy cleanup before sneaking it back into mother's cabinet.
Cristobal Cristo wrote:Thom,
4x4 (100x100 mm) is tiny, much smaller than already small and finicky 4" batchbox firebox (144x215 mm).
If you enlarge the firebox to 8x8x8 and the vertical riser to 3x8 it will draw beautifully. It's much easier to experiment with ordinary red bricks. The stove can be reconfigured while the fire is burning to observe how it affect the combustion.
Thom Bri wrote:I want one small enough to drag around. I want adobe.
Glenn Herbert wrote:You are right that you need more exit airflow, but you could easily get that by making little pillars all around the top instead of a flat top with small grooves in it. I might try six pillars with equal spacing and height as their thickness. Put them toward the outside edge of the top of the chimney so there is just enough inner/upper surface to properly support the smallest pot you want to use.
