Sharpen Loppers - PEP BB tool.straw.loppers

BB tool care - straw badge
posted 5 years ago
  • Likes 2
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
This is a badge bit (BB) that is part of the PEP curriculum.  Completing this BB is part of getting the straw badge in tool care.

Here is a video on how to sharpen loppers.



From the video description:
'Gary Knowlton shows how easy it is to care for and sharpen regular loppers using a sharpening stone."

Requirements to complete:
- Disassemble loppers and sharpen the edge properly (depending on whether anvil or by-pass), including both primary and secondary edge if applicable.
- Remove excess sap and other residue. Some "staining" is to be expected.
- Oil sufficiently for smooth action. Oil can't be petroleum derived .

To get certified for this BB, post the following:

 - Pic of dull edge or poorly cut green stick.
 - Action pic with disassembled loppers showing method of sharpening.
 - Pic of reassembled, sharpened loppers possibly cutting green stick
 - Describe the sharpening method and oil used.
COMMENTS:

K Wagner
Posts: 72
27
posted 3 years ago
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Submission flagged incomplete
- Pic of dull edge or poorly cut green stick.
- Action pic with disassembled loppers showing method of sharpening.
- Pic of reassembled, sharpened loppers possibly cutting green stick
- Describe the sharpening method and oil used.
after oil before i wiped it.
after oil before i wiped it.
gross and dull
gross and dull
disassembled
disassembled
filing the blade
filing the blade
stick
stick
lopped stick
lopped stick
finished product
finished product
Staff note (gir bot) :

Someone flagged this submission as not complete.
BBV price: 1
Note: please describe the oil used


Brandon Gladefield
Posts: 114
Location: VIC, Australia
78
I like...
kids gear cooking building solar homestead
posted 3 years ago
  • Likes 3
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Approved submission
The loppers proved harder than I thought... it was designed to be as difficult to disassemble as possible. But once it was it was full steam ahead with my industrial diamond file and I used the Grinder to get as much of the surface rust as possible because some of the kids had left it outside. Lucky I found it before pruning season. Oil used was rapeseed oil.
All the things gathered
All the things gathered
After much disassembly time I ended up really frustrated
After much disassembly time I ended up really frustrated
Had to grind it off but now disassembled with the intent to get a different nut and bolt to make it easier later
Had to grind it off but now disassembled with the intent to get a different nut and bolt to make it easier later
Dull and frayed edge
Dull and frayed edge
Action shot of the sharpening
Action shot of the sharpening
Pardon the blurry picture but here is the oiling
Pardon the blurry picture but here is the oiling
Good old rapeseed oil
Good old rapeseed oil
The sharpened edge
The sharpened edge

The Lord gave, and the Lord hath taken away; blessed be the name of the Lord. - Job 1:21

Staff note (gir bot) :

Someone approved this submission.
Note: Looks like that edge could be a bit sharper yet but I'd say it's good enough


Brandon Gladefield
Posts: 114
Location: VIC, Australia
78
I like...
kids gear cooking building solar homestead
posted 3 years ago
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Sorry forgot one of the pictures
And assembled all ready to go!
And assembled all ready to go!

The Lord gave, and the Lord hath taken away; blessed be the name of the Lord. - Job 1:21


Sam Russell
Posts: 21
Location: Joplin, MO
22
I like...
homeschooling dog hunting
posted 2 years ago
  • Likes 3
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Approved submission
I spent all last evening trimming branches in and around my fence, then remembered this BB and figured having sharp loppers would probably be a good thing.
Dull loppers
Dull loppers
Dirty loppers
Dirty loppers
Sharpening with a file
Sharpening with a file
Sharpened blade
Sharpened blade
Using what a had on hand, gun oil from Breakthrough
Using what a had on hand, gun oil from Breakthrough
Cleaned, oiled, and sharpened loppers
Cleaned, oiled, and sharpened loppers

It is better to be a warrior in a garden than a gardener in a war.

Staff note (gir bot) :

Mike Barkley approved this submission.


David Huang
gardener
Posts: 1322
741
8
I like...
hugelkultur monies foraging trees composting toilet cooking bike solar wood heat rocket stoves ungarbage
posted 2 years ago
  • Likes 1
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Approved submission
Looking to help my girlfriend with some yard work trimming trees I discovered her loppers were quite dull.  So it was a bb opportunity!

This was a style of lopper that could be easily disassembled for sharpening.  I clamped it in a vise and used a file to rework the cutting edge.  It took a bit of filing as the edge was pretty beat up.  I forgot about the oiling part until I went to submit this bb so I had to go back and do that with some coconut oil that was on hand.
This is a shot of the loppers as they were.
This is a shot of the loppers as they were.
Here is a close up shot of the dull, ragged cutting edge.
Here is a close up shot of the dull, ragged cutting edge.
When trimming a small branch it would as often as not just mash it as see in this shot rather than cutting it.
When trimming a small branch it would as often as not just mash it as see in this shot rather than cutting it.
First I disassemble the loppers.
First I disassemble the loppers.
Pic after I started filing the edge in the vise. Sorry it's blurry, hopefully you can see the irregular bright spots where the file is hitting high points of the ragged edge.
Pic after I started filing the edge in the vise. Sorry it's blurry, hopefully you can see the irregular bright spots where the file is hitting high points of the ragged edge.
Pic of the newly filed edge in the vise. I had to file back a ways to get it all clean, sharp, and free of notches.
Pic of the newly filed edge in the vise. I had to file back a ways to get it all clean, sharp, and free of notches.
The back, flat side needed a bit of careful filing to remove the edge burs.
The back, flat side needed a bit of careful filing to remove the edge burs.
Reassembled and ready to go.
Reassembled and ready to go.
The loppers now neatly cut the same branch just below where it mangled it previously.
The loppers now neatly cut the same branch just below where it mangled it previously.
Forgot the oiling part until I was submitting this bb. Went back and oiled it with some coconut oil, though it had now been used to do a lot of tree trimming!
Forgot the oiling part until I was submitting this bb. Went back and oiled it with some coconut oil, though it had now been used to do a lot of tree trimming!

You are welcome to check out my blog at http://www.theartisthomestead.com or my artwork at http://www.davidhuang.org

Staff note (gir bot) :

L. Johnson approved this submission.
Note: I hereby certify this badge bit complete.


Timothy Norton
master gardener
Posts: 4321
Location: Upstate NY, Zone 5, 43 inch Avg. Rainfall
1754
I like...
monies home care dog fungi trees chicken food preservation cooking building composting homestead
posted 1 year ago
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Approved submission
To get certified for this BB, post the following:

- Pic of dull edge or poorly cut green stick.
- Action pic with disassembled loppers showing method of sharpening.
- Pic of reassembled, sharpened loppers possibly cutting green stick
- Describe the sharpening method and oil used.

These loppers come from my grandfather who gave them to my mother and then to me. They have been beaten for years and put away wet. I found some time on Christmas to break out a file and get to work sharpening it up. I was surprised how well it took a blade! Knocked it out in no time. I am using beeswax as a lubricant as I find it to work really well with my simple actioned hand tools. If it hits a friction point, it can melt into it and keep the actions smooth. So far so good.
Old loppers that have been around forever
Old loppers that have been around forever
Dissasembly
Dissasembly
Dissasembled
Dissasembled
Flat File
Flat File
Beeswax will be my lubricant of choice
Beeswax will be my lubricant of choice
Before Blade
Before Blade
After Blade
After Blade
Reassembled
Reassembled

- Tim's Homestead Journal - Purchase a copy of Building a Better World in Your Backyard - Purchase 6 Decks of Permaculture Cards -
- Purchase 12x Decks of Permaculture Cards - Purchase a copy of the SKIP Book - Purchase 12x copies of Building a Better World in your Backyard

Staff note (gir bot) :

David Huang approved this submission.
Note: I hearby certify this complete.


Rebekah Harmon
Apprentice Rocket Scientist
Posts: 872
Location: 4a, high mountain dessert
428
3
I like...
kids foraging rabbit fiber arts medical herbs bee
posted 6 months ago
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Approved submission
My loppers are struggling to slice. I used a two sided whetstone on them. Then honed the blade side. Afterwards, I scrubved off some rust with a wire brish amd oiled it with walnut oil.
Dull rusty loppers
Dull rusty loppers
Taken apart, using a whetstone
Taken apart, using a whetstone
A clean cut greenstick, with reassembled loppers
A clean cut greenstick, with reassembled loppers

Being weird is easy. Making it mainstream is hard. Be brave! https://www.youtube.com/@healthygreenbrave

Staff note (gir bot) :

Jeremy VanGelder approved this submission.


Alexandra Malecki
gardener
Posts: 434
Location: 6a; BSk; Suburbia; 0.35 acres
185
5
I like...
kids forest garden foraging bike medical herbs rocket stoves
posted 1 week ago
  • Likes 1
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
    Send
  • Quote
  • Report post to moderator
Approved submission

Dave Burton wrote:sharpen loppers

Requirements to complete:
- Disassemble loppers and sharpen the edge properly (depending on whether anvil or by-pass), including both primary and secondary edge if applicable.
- Remove excess sap and other residue. Some "staining" is to be expected.
- Oil sufficiently for smooth action. Oil can't be petroleum derived .

To get certified for this BB, post the following:

 - Pic of dull edge or poorly cut green stick.
 - Action pic with disassembled loppers showing method of sharpening.
 - Pic of reassembled, sharpened loppers possibly cutting green stick
 - Describe the sharpening method and oil used.



I love these loppers, they're the perfect size for me and they're definitely due for a sharpening. After disassembling the loppers, I used a 400 grit sharpening stone, then a 1000 grit sharpening stone, then a leather strop, then oiled it using flaxseed oil, then reassembled it.
[Thumbnail for 1_before-dull-cut.jpg]
[Thumbnail for 1_before-up-close-rusty-dull-edge.JPG]
[Thumbnail for 1_loppers-before.JPG]
[Thumbnail for 2_action-shot-of-disassembled-loppers-with-400-grit-block.JPG]
[Thumbnail for 3_flaxseed-oiled.JPG]
[Thumbnail for 3_paper-test-of-sharp-edge-before-reassembly.jpg]
[Thumbnail for 3_up-close-of-sharp-edge-after-reassembly.JPG]

I'm pursuing SKIP to inherit property, check it out for yourself: SKIP book
I love that Rocket Mass Heaters are Carbon-Nuetral. In Erica's and Ernies Art of Fire Presentation, Erica explains the chemistry of how that's possible!

Staff note (gir bot) :

David Huang approved this submission.
Note: I hearby certify this complete.
